Iloilo Bike Shop
Checkpoint ALR 4
Checkpoint ALR 4
Regular price
₱104,990.00 PHP
Regular price
Sale price
₱104,990.00 PHP
Unit price
/
per
Couldn't load pickup availability
*Please note - spec applies to all sizes unless listed separately
Frameset
| Frame | 300 Series Alpha Aluminum, tapered head tube, Internal cable routing, 3S chain keeper, T47 BB, rack and fender mounts, integrated frame bag mounts, flat mount disc, 142x12mm thru axle |
|---|---|
| Fork | Checkpoint, full carbon, tapered carbon steerer, rack mounts, fender mounts, flat mount disc, 12x100mm thru axle |
Weight
| Weight | 56 - 9.91 kg / 21.85 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
Drivetrain
| Shifter | SRAM Apex, 11 speed |
|---|---|
| Rear derailleur | SRAM Apex 1, long cage, 42T max cog |
| *Crank |
Size: 49 SRAM Apex 1, 40T, DUB Wide, 165mm length |
|
Size: 52 SRAM Apex 1, 40T, DUB Wide, 170mm length |
|
|
Size: 54, 56 SRAM Apex 1, 40T, DUB Wide, 172.5mm length |
|
|
Size: 58, 61 SRAM Apex 1, 40T, DUB Wide, 175mm length |
|
| Bottom bracket | SRAM DUB Wide, T47 threaded, internal bearing |
| Cassette | SRAM PG-1130, 11-42, 11 speed |
| Chain | SRAM PC-1130, 11 speed |
| Max chainring size | 1x: 44T (SRAM), 50T (Shimano), 2x: 50/34 |
Wheels
| Hub front | Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle |
|---|---|
| Skewer front | Bontrager Switch thru axle, removable lever |
| Hub rear | Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle |
| Skewer rear | Bontrager Switch thru axle, removable lever |
| Rim | Bontrager Paradigm, Tubeless Ready, 24-hole, 21mm width, Presta valve |
| Spokes | 14g stainless steel, black |
| *Tire |
Size: 49, 52, 54, 56, 58, 61 Bontrager GR1 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 120 tpi, 700x40mm |
|
Size: 49, 52, 54, 56, 58, 61 Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42mm |
|
| Tire part | Bontrager TLR sealant, 6oz |
| Rim strip | Bontrager TLR |
| Max tire size | See service manual |
Components
| *Saddle |
Size: 49, 52 Bontrager Verse Comp, steel rails, 155mm width |
|---|---|
|
Size: 54, 56, 58, 61 Bontrager Verse Comp, steel rails, 145mm width |
|
| Seatpost | Bontrager alloy, 27.2mm, 12mm offset, 330mm length |
| *Handlebar |
Size: 49 Bontrager Elite Gravel, 38cm width |
|
Size: 52 Bontrager Elite Gravel, 40cm width |
|
|
Size: 54, 56 Bontrager Elite Gravel, 42cm width |
|
|
Size: 58, 61 Bontrager Elite Gravel, 44cm width |
|
| Handlebar tape | Bontrager Supertack Perf tape |
| *Stem |
Size: 49 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length |
|
Size: 49 Bontrager Elite, 31.8mm clamp, Blendr compatible, 7 degree, 70mm length |
|
|
Size: 52, 54 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length |
|
|
Size: 56, 58 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length |
|
|
Size: 61 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length |
|
| Brake | Tektro C550 mechanical disc brake, dual piston, flat mount |
| Brake rotor | Tektro, centerlock, 160mm |
| Rotor size | Max brake rotor sizes: 160mm front & rear |
